CAMERA
Sensor: 1/2.7-in HD progressive scan CMOS
Lens: f=8.0mm, F1.6, Diagonal 45°, Horizontal 40°, Vertical 22°
Camera Angle: Pan 350°, Tilt 65° (manual control)
ICR Control: Auto (Day & Night)
Synchronization: Internal
White Balance: ATW/AWB
DNR: Built-in 2D/3D DNR
WDR: 110 dB
Flickerless Control: Auto, 50 Hz, 60 Hz
Image Rotation: Flip, Mirror, 180°
Image Setting: Manual (saturation, sharpness, contrast)
AGC: 2X, 4X, 8X, 16X, 32X, 64X
Minimum Illumination: Color: 0.2 lux @ F1.2, B/W: 0.05 lux @ F1.2
Electronic Shutter: Auto, Fixed (1/30 to 1/25000 sec)
S/N Ratio: Max 50 dB (AGC off, DNR on)
INTERFACE
Ports: 1 x 10/100BaseT(X)
Connector: M12 D-coded 4-pin female
Typical Distance: -
VIDEO
Compression: H.264 (ISO/IEC 14496-10), MJPEG
Output: Via Ethernet
Streams: 3 independent H.264 or MJPEG streams
Viewing Features: DynaStream™, CBR Pro™, 3 privacy masks, adjustable image size/quality, timestamp/text overlay, OSD position adjustable, 5 unicast connections max, 50 multicast clients
AUDIO
Inputs: -
Format: -
Outputs: -
NETWORK
Protocols: TCP/IP, IPv4, UDP, HTTP, RTP/RTSP, ARP, UPnP, FTP, TFTP, SMTP, NTP Client, DNS, DDNS, QoS, IGMP v3, ICMP, SNMPv1/v2c/v3, DHCP Opt66/67, HTTPS
POWER REQUIREMENTS
Power Information: PoE (IEEE 802.3af), 0.35 A @ 48 VDC
ALARMS
Intelligent Video: Camera tampering detection
Motion Detection: 3 configurable areas
Scheduling: Daily repeat timing
Snapshot Buffer: 12 MB pre/trigger/post JPEG images
Custom Alarms: HTTP events
Messaging: Email/FTP image transfer
SECURITY
Password Protection: User-level
Filtering: IP address
Encryption: HTTPS
Authentication: -
PHYSICAL CHARACTERISTICS
Dimensions: 125 x 125 x 120.7 mm (4.92 x 4.92 x 4.8 in)
Weight: 810 g (1.79 lb)
Operating Temperature: -40 to 70°C (-40 to 158°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Housing: IP66, metal, PC dome, IK10
Installation: Panel mount
MTBF: 1,598,728 hrs
STANDARDS AND CERTIFICATIONS
EMI: CISPR 32, FCC Part 15B Class A
EMS: IEC 61000-4-2/3/4/5/6/8
Freefall/Shock/Vibration: IEC 60068-2-31/27/64, IEC 61373, EN 50155
Fire Protection: EN 45545-2
Safety: UL 60950-1
Ingress Protection: IEC 60529, IP66
Vandal Resistance: EN 62262, IK10
Salt Spray: ASTM-B117
Railway Compliance: EN 50155 (partial)
Altitude: 2000 m
MINIMUM VIEWING SYSTEM REQUIREMENTS
Memory Size: 1 GB
OS: Windows 7 or above
Browser: Internet Explorer 9.x or above
Multimedia: DirectX 9.0C or above
SOFTWARE DEVELOPMENT
SDK: VPort SDK PLUS (CGI, ActiveX, API)
Standard: ONVIF Profile S
