Camera
Sensor: 1/3-in 3-megapixel progressive scan CMOS
Lens: f=2.4 mm, F2.0, Diagonal 139°, Horizontal 110°, Vertical 81°
Camera Angle: Pan ±15°, Tilt 20° to 90° (controlled manually)
ICR Control (for day & night): Auto (light sensor control) or DI control
IR Illumination: Not available
Synchronization: Internal
White Balance: ATW/AWB
DNR: Built-in 2D/3D DNR
WDR: 100 dB
Flickerless Control: Automatic, 50 Hz, 60 Hz modes
Image Rotation: Flip, Mirror, 90°, 180°, 270° rotation
Image Setting: Manual tuning with saturation, sharpness, and contrast
AGC (Auto Gain Control): 2X, 4X, 8X, 16X
Minimum Illumination: Color: 0.2 lux at F1.2 (Gain High, 50 IRE, 1/30 sec)
Electronic Shutter: Auto, Fixed (1/30 to 1/25000 sec)
S/N Ratio: Maximum 50 dB (AGC off; DNR on)
Interface
10/100BaseT(X) Ports: -
PoE Ports: 1 x 10/100BaseT(X), M12 D-coded 4-pin female connector
Digital Input/Output Channels: 1 x Digital Input Channel (M12 connector with 20 cm cable)
Relay Channels: -
Audio
Audio Inputs: 1 x line-in, with M12 connector
Audio Format: Mono, PCM (G.711), AAC
Audio Outputs: -
Video
Video Compression: H.265 (MPEG-H part 2/HEVC), H.264 (ISO/IEC 14496-10), or MJPEG
Video Output: Via Ethernet
Video Streams: 4 independent video streams
Video Viewing: DynaStream™ support for changing the video frame rate automatically; CBR Pro™ for good image quality in limited bandwidth transmissions; 3 privacy mask areas provided; Adjustable image size and quality; Timestamp and text overlay; OSD (On Screen Display) position adjustable; Maximum of 10 simultaneous unicast connections; 50 multicast clients
Network
Protocols: TCP/IP, IPv4/IPv6, UDP, HTTP, RTP/RTSP, ARP, UPnP, FTP, TFTP, SFTP, NTP Client, DNS, QoS, IGMP v3, ICMP, SNMPv1/v2c/v3, DHCP Opt66/67, HTTPS
Power Requirements
Input Voltage: PoE (IEEE 802.3af)
Input Current: 48 VDC @ 0.137 A
Source of Input Power: PoE (IEEE 802.3af)
Alarms
Intelligent Video: Camera tampering detection
Video Motion Detection: 3 independently configurable areas
Imaging: JPEG snapshots for pre/trigger/post alarm images
Custom Alarms: HTTP event servers for setting customized alarm actions
Email/FTP Messaging: Automatic transfer of stored images via FTP as event-triggered actions
Pre-alarm Buffer: 50 MB video buffer for JPEG snapshot images
Security
Password: User-level password protection
Filtering: IP address
Encryption: HTTPS
Authentication: -
General
MTBF: 997,474 hrs
microSD Slot: -
Physical Characteristics
Housing: IP66 rain and dust protection, Metal housing, PC dome cover, IK8 vandal-resistant protection
Dimensions: 110 x 115.5 x 61.8 mm (4.33 x 4.53 x 2.43 in)
Weight: 620 g (1.37 lb)
Installation: Panel mounting
Operating Temperature: -40 to 55°C (-40 to 131°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Standards and Certifications: EMI: CISPR 32, FCC Part 15B Class A; EMS: IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV, IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m, IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV, IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV, IEC 61000-4-6 CS: 10 V, IEC 61000-4-8 PFMF; Freefall: IEC 60068-2-31; Railway Fire Protection: EN 45545-2; Safety: UL 62368-1; Shock: IEC 60068-2-27, IEC 61373, EN 50155; Vibration: IEC 60068-2-64, IEC 61373, EN 50155; Railway: EN 50155 (complies with a portion of EN 50155 specifications); Ingress Protection: IEC 60529, IP66; Vandal Resistance: EN 62262, IK8; Altitude: 2000 m
Minimum Viewing System Requirements
Memory Size: 8 GB
Operating System: Windows 10 or above
Browser: Internet Explorer 11 or above; Chrome: Version 118 or above; Microsoft Edge: Version 118 or above
Multimedia: DirectX 12 or above
Software Development
VPort SDK PLUS: -
Standard: ONVIF Profile S, T, M
