Switch and Hub : Interface
Number of Ports: 16 Ports
10/100Mb RJ45 (Megabit) Ports: No
10/100/1000Mb RJ45 (Gigabit) Ports: No
100Mb Fiber Optic Multi Mode (Megabit) Ports: No
100Mb Fiber Optic Single Mode (Megabit) Ports: No
1000Mb SFP Fiber Optic (Gigabit) Ports: No
10/100Mb (Megabit) POE Ports: Yes: 8 x 10/100BaseT(X) PoE ports with M12 D-coded 4-pin female connector
100Mb SFP Fiber Optic (Megabit) Ports: No
10/100/1000Mb (Gigabit) POE Ports: No
M12 Port: Yes
Serial Port: Yes: 1 x Console Port with M12 A-coded male connector
USB: No
Other Ports: 8 x 10/100BaseT(X) ports with M12 D-coded 4-pin female connector
Switch and Hub : Features and Capabilities
Backup: -
Switch and Hub : LED Indicators
LED Per Port: Yes
Switch and Hub : Power Requirements
Maximum Power Consumption: -
Power Consumption (Output Adapter): 16.8 to 137.5 VDC
Power Input Plugin (Redundant): No
Switch and Hub : General
Fan / Fanless: Fanless
MTBF: 483,246 hrs
Switch and Hub : Switch Specifications
Most Forwarding Speed: -
Network Working Layers: Layer 2
Switch Type: Managed
Port Aggregation: -
Switch and Hub : Physical Characteristics
Dimensions: 250 x 176.2 x 115 mm (9.84 x 6.9 x 4.53 in)
Housing: Metal
Installation: DIN-rail mounting (optional), Wall mounting
Operation Humidity: 5 to 95% (non-condensing)
Storage Humidity: -
Standards and Certifications: EMS, IEC 60068-2-31, FCC, Railway, EN 45545-2, EN 62368-1, Shock, Vibration, EN 55032/35
Switch and Hub : Standards and Protocols
Protocols and Work Standards:
IEEE 802.1D-2004 (Spanning Tree Protocol), IEEE 802.1p (Class of Service), IEEE 802.1Q (VLAN Tagging), IEEE 802.1s (Multiple Spanning Tree Protocol), IEEE 802.1w (Rapid Spanning Tree Protocol), IEEE 802.1X (Authentication), IEEE 802.3 (10BaseT), IEEE 802.3ab (1000BaseT(X)), IEEE 802.3ad (Port Trunk with LACP), IEEE 802.3u (100BaseT(X)/100BaseFX), IEEE 802.3x (Flow Control), IEEE 802.3af/at (PoE/PoE+ Output), IEEE 802.3z (1000BaseSX/LX/LHX/ZX)
Protocols and Management Standards:
Account Management, Back Pressure Flow Control, DHCP Client (Options 1/3/50/51/53/54/55/57/66/67), DHCP Option 82 (Relay Agent), DHCP Server (Options 1/3/12/15/42/50/55), Flow Control, HTTP, ICMP, IPv4/IPv6, LLDP, Loop Protection, Port-Based DHCP Server, Port Mirror, QoS/CoS/ToS, RARP, RMON, SMTP, SNMP Inform, SNMP Trap, SNMPv1/v2c/v3, Syslog, Telnet
Switch and Hub : Package Checklist
Hardware Installation Guide: Yes
Power Adapter: -
Power Cable: -
