Switch and Hub: Interface
Number of Ports: 6 Ports
10/100Mb RJ45 (Megabit) Ports: 6 Ports
10/100/1000Mb RJ45 (Gigabit) Ports: No
100Mb Fiber Optic Multi-Mode (Megabit) Ports: No
100Mb Fiber Optic Single-Mode (Megabit) Ports: No
1000Mb SFP Fiber Optic (Gigabit) Ports: No
10/100Mb (Megabit) POE Ports: No
100Mb SFP Fiber Optic (Megabit) Ports: No
10/100/1000Mb (Gigabit) POE Ports: No
Other Ports: No
Switch and Hub: Features and Capabilities
Backup: Yes
Switch and Hub: LED Indicators
LED Per Port: Yes
Switch and Hub: Power Requirements
Power Consumption (Output Adapter): 4.75 W
Power Input Plugin (Redundant): Yes
Input Voltage: 12-48 VDC, Redundant dual inputs
Operating Voltage: 9.6 to 60 VDC
Input Current: 0.76 A max. @ 12-48 VDC
Switch and Hub: General
Fan / Fanless: Fanless
MTBF: 3,483,278 hrs
Switch and Hub: Switch Specifications
Most Forwarding Speed: -
Network Working Layers: Layer 2
Switch Type: Smart Ethernet Switch
Port Aggregation: -
Switch and Hub: Physical Characteristics
Housing: Metal
Installation: DIN-rail mounting, Wall mounting (with optional kit)
Operation Humidity: 5 to 95% (non-condensing)
Switch and Hub: Standards and Certifications
Standards and Certifications: EMC, EMI, EMS, Safety, Shock, Freefall, Vibration
Switch and Hub: Standards and Protocols
Protocols and Work Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D-2004, IEEE 802.1w, IEEE 802.1Q, IEEE 802.1p
Protocols and Management Standards: EtherNet/IP, Modbus TCP, PROFINET IO Device, Back Pressure Flow Control, DHCP Client, Flow Control, IPv4/IPv6, LLDP, Port Mirror, SNMP Inform, SNMPv1/v2c/v3, Syslog, RSTP, STP, MRP (Client), HTTPS/SSL, SNMPv3, Port Lock, NTP Server/Client, SNTP, 802.1Q VLAN
Switch and Hub: Package Checklist
Hardware Installation Guide: Yes
Power Adapter: No
Power Cable: No
