Moxa

MOXA NE-4110S MODULE

MOXA NE-4110S MODULE

Regular price $100.00 CAD
Regular price Sale price $100.00 CAD
Sale Sold out

Features and Benefits

  •  10/100 Mbps Ethernet interface
  •  Supports baudrates up to 230.4 kbps
  •  Choice of operation modes: Real COM, TCP Server, TCP Client, and UDP
  •  Supports DHCP, BootP, Static IP, and ARP
  •  SNMP and email alerts for event trapping and notifications
  •  Half the size of a credit card—only 57 × 40 mm
  •  Low power consumption at 1.5 W, with single +5 V input
View full details

Description

Moxa’s NE-4100 embedded device servers are designed for manufacturers who want to add sophisticated network connectivity to their serial devices. Moxa’s embedded device servers can be used to convert any device with a standard serial interface to an Ethernet-enabled device in no time. The NE-4100 embedded device servers support 10/100 Mbps Ethernet, and provide ready-to-use operation modes, including TCP Server, TCP Client, and UDP. In addition, a Real COM driver is included for backward compatibility with legacy software.

Specification

Platform: CPU 16-bit MCU, Memory Flash 2 MB, SDRAM 1 MB
Input/Output Interface: Configurable DIO Channels (by software) 4
Ethernet Interface: 10/100BaseT(X) Ports, Auto MDI/MDI-X NE-4120S/4120A: 5-pin pin header NE-4100T: 26-pin dual-in-line NE-4110S/4110A: 8-pin RJ45, Magnetic Isolation Protection 1.5 kV (built-in), Standards IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X) IEEE 802.3x for flow control
Ethernet Software Features: Configuration Options Web Console (HTTP), Windows Utility, Telnet Console, Serial Console, Management ARP, Device Search Utility (DSU), DHCP Client, HTTP, IPv4, SMTP, SNMPv1/v2c, TCP/IP, Telnet, UDP, Web Console, ICMP, Windows Real COM Drivers Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1/10 (x86/x64), Windows 2008 R2/2012/2012 R2/2016/2019 (x64), Windows Embedded CE 5.0/6.0, Windows XP Embedded, Linux Real TTY Drivers Kernel versions: 2.4.x, 2.6.x, 3.x, 4.x, and 5.x, Fixed TTY Drivers SCO UNIX, SCO OpenServer, UnixWare 7, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac OS X, Android API Android 3.1.x and later
Serial Interface: No. of Ports 2 (1 for serial interface, 1 for TTL console port), Serial Standards NE-4110S/4120S: RS-232 NE-4110A/4120A: RS-422, RS-485 NE-4100T: TTL, Operation Modes Real COM mode, TCP Client mode, TCP Server mode, UDP mode, Baudrate 110 bps to 230.4 kbps, Data Bits 5, 6, 7, 8, Stop Bits 1, 1.5, 2, Parity None, Even, Odd, Space, Mark, Flow Control None, RTS/CTS, DTR/DSR, XON/XOFF
Serial Signals: RS-232 NE-4110S/4120S: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND, RS-422 NE-4110A/4120A: TX+, TX-, RX+, RX-, GND, RS-485-4w NE-4110A/4120A: TX+, TX-, RX+, RX-, GND, RS-485-2w NE-4110A/4120A: Data+, Data-, GND
Power Parameters: Input Voltage 5 VDC, Power Consumption 290 mA @ 5 VDC
Physical Characteristics: Dimensions NE-4110/4120: 57 x 40 mm (2.24 x 1.57 in) NE-4100T: 45 x 36 mm (1.77 x 1.42 in), Weight NE-4110S/4110A: 40 g (0.09 lb) NE-4120S/4120A/4100T: 20 g (0.04 lb), Form Factor Type NE-4110/4110A/4120S/4120A: Ready-to-go pin header modules NE-4100T: Drop-in modules
Environmental Limits: Operating Temperature Standard Models: 0 to 55˚C (32 to 131˚F) Wide Temp. Models: -40 to 75˚C (-40 to 167˚F), Storage Temperature (package included) -40 to 60°C (-40 to 140°F), Ambient Relative Humidity 5 to 95% (non-condensing)
Standards and Certifications: EMC EN 55032/24, EMI CISPR 32, FCC Part 15B Class A, EMS IEC 61000-4-2 ESD, IEC 61000-4-3 RS, IEC 61000-4-4 EFT, IEC 61000-4-5 Surge, IEC 61000-4-6 CS, IEC 61000-4-8 PFMF, Environmental Testing IEC 60068-2-1 IEC 60068-2-3 IEC 60068-2-14
Declaration: Green Product RoHS, CRoHS, WEEE
MTBF: Time NE-4100T: 288,173 hrs NE-4110S: 290,276 hrs NE-4110A/4120S/4120A: 289,573 hrs, Standards Telcordia SR332
