Modular Controller: Computer
CPU: 32-bit Cortex-A8 1GHz
OS: Real-time Linux (PREEMPT_RT)
RAM: 512 MB DDR3(L)
MicroSD Slot: microSD Slot Up to 32 GB (SD 2.0 compatible)
Modular Controller: Control Logic
Language: C/C++
Modular Controller: Ethernet Interface
LAN Ports: 2 x 10/100BaseT(X) Ports (RJ45)
Magnetic Isolation Protection: 1.5 kV (built-in)
Modular Controller: Serial Interface
Number of Ports: 1 x RS-232 (TxD, RxD, GND), 3-pin (115200, n, 8, 1)
Serial Standards: RS-232
Modular Controller: Power Requirements
Input Voltage: 24 to 110 VDC
Power Consumption: 223 mA @ 24 VDC
Power Connector: Spring-type Euroblock terminal
Modular Controller: General
MTBF: 1,358,656 hrs
Standards and Certifications: EMC, EMI, EMS, EN 50121-4, EN 50155, Safety, Shock, Vibration
Supported Protocols: Modbus TCP Client (Master), Modbus TCP Server (Slave), Moxa AOPC (Active Tag), SNMPv1/v2c Trap, SNMPv1/v2c/v3, BOOTP, IPv4, SMTP, UDP, TCP/IP
Modular Controller: Physical Characteristics
Housing: Metal
Dimensions: 205.65 x 133.35 x 100 mm (8.1 x 5.25 x 3.94 in)
Weight: 2.56 kg (5.64 lb)
Installation: Wall mounting (with optional kit)
Operating Temperature: -40 to 75°C (-40 to 167°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
