Moxa

MOXA IM-6700A-2MSC4TX Fast Ethernet Module

$611.00 CAD

Special Offer Out of Stock

Product variants

Features and Benefits

4 x 10/100BaseT(X) Ports (RJ45 Connector)
2 x 100BaseFX Ports (Multi-Mode, ST Connectors)
5 KM typical data transmission distance for fiber ports
Compatible with IKS-6726A-2GTXSFP/6728A-4GTXSFP/6728A-8PoE-4GTXSFP modular managed switches

View full details

Description

Data sheet

Specification

Modules: Interface
Ports: 2 x 100BaseFX ports, 4 x 10/100BaseT(X) ports
Connector: Multi-mode SC for FX ports, RJ45 for T(X) ports
Typical Distance: 5 km (max.)

Modules: Power Requirements
Power Information: Power Consumption: 3.19 W (max.)

Modules: Physical Characteristics
Ambient Relative Humidity: -
Standards and Certifications: Telcordia (Bellcore), GB
Size: -
Net Weight: 270 g (0.60 lb)
Temperature: -
MTBF: 7,356,096 hrs
