Input/Output Interface:
Alarm Contact Channels: 1
Relay Output: 1 A @ 24 VDC
Buttons: Reset button
Digital Input Channels: 1
Digital Input Voltage Range: +13 to +30 V for state 1, -30 to +3 V for state 0
Max Input Current: 8 mA
Ethernet Interface:
10/100BaseT(X) Ports: 14 (EDS-518E-4GTXSFP), 12 (other models)
Combo Ports: 4 (10/100/1000BaseT(X) or 100/1000BaseSFP+)
Fiber Ports Multi-Mode SC: 2 (EDS-518E-MM-SC-4GTXSFP)
Fiber Ports Multi-Mode ST: 2 (EDS-518E-MM-ST-4GTXSFP)
Fiber Ports Single-Mode SC: 2 (EDS-518E-SS-SC-4GTXSFP)
Software Features:
Protocols: EtherNet/IP, Modbus TCP, PROFINET IO Device
Redundancy: Turbo Ring, Turbo Chain, MSTP, RSTP, STP, MRP
Security: HTTPS, SSH, TACACS+, RADIUS, SNMPv3, MAC ACL
Management: LLDP, Port Mirror, DHCP Options 66/67/82
Switch Properties:
IGMP Groups: 2048
MAC Table: 16 K
Max VLANs: 64
Packet Buffer Size: 1 Mbit
Physical Characteristics:
Dimensions: 94 x 135 x 137 mm
Weight: 1630 g
Installation: DIN-rail, Wall mounting (optional)
Environmental and Standards:
Operating Temperature: -10 to 60°C (Standard), -40 to 75°C (Wide-Temp)
Certifications: UL 508, EN 62368-1, ATEX, IEC 61850-3
Power Specifications:
Input Voltage: 9.6 to 60 VDC
Redundant Inputs: Supported
Overload Protection: Supported
Reverse Polarity Protection: Supported
Warranty:
Period: 5 years
