MOXA EDS-510E-3GTXSFP MANAGED ETHERNET SWITCH

MOXA EDS-510E-3GTXSFP MANAGED ETHERNET SWITCH

$1,892.00 CAD
$1,892.00 CAD
Sale Sold out
We have 1 in stock

Features and Benefits

  • 7 x 10/100Mbps T(x) ports and 3 x Gigabit Combo ports
  • Din-rail
  • Metal body
  • -10 to 60°C operating temperature
View full details

Description

The EDS-510E Gigabit managed Ethernet switches are designed to meet rigorous mission-critical applications, such as factory automation, ITS, and process control. The 3 Gigabit Ethernet ports allow great flexibility to build up a Gigabit redundant Turbo Ring and a Gigabit uplink. The switches have USB interfaces for switch configuration, system file backup, and firmware upgrade, making them easier to manage.

You can also find the EDS-510E-3GTXSFP-T models in the EDS-510E series.

Data sheet

Specification

Number of ports: 10 Ports
10/100Mb RJ45 (Megabit) Ports: 7 Ports
10/100/1000Mb RJ45 (Gigabit) Ports: 3 Ports
1000Mb SFP Fiber optic (Gigabit) Ports: 3 Ports
Power Consumption: 24V DC, 0.68A
MTBF: 723532 hour
Switch type: Managed
Dimensions: 79.2x135x116mm
Housing: Metal
Installation: Din-rail
Operating Temperature: -10 to 60°C
Operation Humidity: 5% to 95% RH non-condensing
Standards and Certifications: FCC, UL 508, UL/cUL Class 1 Div. 2, ATEX Zone 2, NEMA TS2, IEEE 1613, IP30
