Slot type: T-slot
Dimension: 23.5 x 5 x 5.5 mm
Principle of operation: Magnetic field sensor
Connection: M12x1-Male, 4-pin, A-coded
Cable: PUR, 0.3 m
Application: Pneumatic cylinder with T-slot. For dimensions, see sketch in product view.
Mounting part: Can be installed in T-slot from above
Housing material: PA 12
Switching output: PNP normally open (NO)
Switching frequency: 3000 Hz
Operating voltage Ub: 10...30 VDC
Ambient temperature: -25...85 °C
IP rating: IP67
Approval/Conformity: CE, UKCA, cULus, WEEE
