10/100Mb RJ45 (Megabit) Ports: Yes (1 Port)
RS-232 Ports: Yes (1 Port)
RS-422/485 Ports: Yes (1 Port)
Serial connection type: TB
Serial Communication Parameters: Data Bits: 5, 6, 7, 8 and Stop Bits: 1, 1.5, 2, Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF
Data transfer speed (Baudrate): 0.11Kbps to 230.4Kbps
Protection against electrostatic discharge: 15KV
Management: Web Console, Serial Console, Telnet Console, Windows Utility
MTBF: 279122 hour
Compatible operating systems: Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1 (x86/x64), Windows 2008 R2/2012/2012 R2 (x64), Windows Embedded CE 5.0/6.0, Windows XP Embedded
Fixed TTY Drivers: SCO Unix, SCO OpenServer, UnixWare 7, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac OS X
Linux Real TTY Drivers: Linux 2.4.x, 2.6.x, 3.x
Power Consumption (Output Adapter): 12V DC, 0.12A to 48V DC
The automatic restart (reset): Yes (WDT)
Network protocol: ICMP, IPv4, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP
Dimensions: 52x80x22mm
Safety: UL 60950-1, EN 60950-1
EMC: FCC, CE
EMI: EN 55022 Class B, FCC Part 15 Subpart B Class A
EMS: EN 55024
LAN port Protection against magnetic fields: 1.5KV
Housing: Metal
Operating Temperature: -40 to 75°C
Storage Temperature: -20 to 75°C
Altitude: 2000m
Operation Humidity: 5% to 95% RH non-condensing
Weight: 0.36Kg
