3G Modem : Interface
10/100BaseT(X) Ports: 8
100/1000BaseSFP Slots: 2
Alarm Contact Channels: Resistive load: 1 A @ 24 VDC
Digital Input Channels: +13 to +30 V for state 1, -30 to +3 V for state 0, Max. input current: 8 mA
3G Modem : Software Specifications
Routing Redundancy: RSTP, STP, Turbo Ring v2
Time Management: NTP Server/Client, SNTP
Routing Throughput: Max. 50K packets per second / 500 Mbps (based on RFC 2544)
3G Modem : General
Broadcast Forwarding: IP directed broadcast, broadcast forwarding
Multicast Routing: Static Route
Management: Back Pressure Flow Control, DDNS, DHCP, Server/Client, Web Console (HTTP/HTTPS), LLDP, QoS/CoS/ToS, SNMPv1/v2c/v3, Telnet, TFTP, HTTPS, SSH
MTBF: 1,347,225 hrs
3G Modem : Standards and Protocols
Protocols: IPsec L2TP (server) PPTP (client)
Redundancy Protocols: RSTP, STP, Turbo Ring v2
3G Modem : Security
Security and Encryption: Security: Secure Boot, IPsec, L2TP (server), RADIUS, Trust access control; Encryption: DES, 3DES, AES-128, AES-192, AES-256, AES-256-GCM
Authentication: MD5 and SHA (SHA-256) RSA (key size: 1024-bit, 2048-bit) X.509 v3 certificate
3G Modem : Power Requirements
Connection: Removable terminal block
Input Voltage: 12/24/48 VDC, redundant dual inputs (DNV-certified for 24 VDC)
Reverse Polarity Protection: Supported
3G Modem : Buttons
Buttons: Reset button
3G Modem : Physical Characteristics
Dimensions: 45 x 135 x 105 mm (1.77 x 5.31 x 4.13 in)
Housing: Metal
Weight: 520 g (1.15 lb)
Operating Temperature: -10 to 60°C (14 to 140°F)
Storage Humidity: 5 to 95% (non-condensing)
Storage Temperature: -40 to 85°C (-40 to 185°F)
3G Modem : Standards and Certifications
Safety, EMC, EMI, EMS, EN 50121-4, NEMA TS2, IEC 60945, DNV, Shock, Freefall, Vibration, IEC 61850-3 Edition 2.0, IEEE 1613, Hazardous Locations: (ATEX, Class I Division 2, IECEx)
